Great financing available at motozilli.com Engine Type: 4-Stroke, single cylinder, DOHC
Displacement: 652cc
Bore and Stroke: 100.0 x 83.0mm
Compression Ratio: 9.8:1
Fuel System: DFI w/40mm Throttle Body
Ignition: Cdi
Transmission: 5-speed, return shift with wet multi-disc manual clutch
Final Drive: Sealed Chain
Front Suspension: 41mm telescopic fork/ 7.9 in. travel
Rear Suspension: Uni-Trak®, single shock with adjustable rebound damping and adjustable spring preload / 7.3 in. travel
Front Brakes: Single 300mm disc with 2-piston calipers (and ABS)
Rear Brakes: Single 240mm disc with single-piston caliper (and ABS)
Front Tire: 90/90-21
Rear Tire: 130/80-17
Wheelbase: 60.6 in.
Seat Height: 34.3 in.
Rake: 30.0 deg.
Trail: 4.8 in.
Fuel Capacity: 6.1 gal.
Dry Weight: Curb Weight: Non ABS: 456.2 lb. / ABS: 460.6 lb.
Colors: Pearl Storm Gray, Pearl Solar Yellow, Candy Lime Green
