Engine Type: Single-Cylinder
Displacement: 27 cu. in. (443 cc)
Bore x Stroke: Bore: 3.5 in. (89 mm); Stroke: 2.81 in. (71.2 mm)
Cylinders: 1
Engine Cooling: Liquid
Fuel System: Gas
Starting System: Electric
Alternator: 10
Front Suspension: Independent Double A-Arm
Front Travel: 7.8 in. (198.1 mm)
Front Brake Type: Dual Hydraulic Disc
Front Tires: AT 23 X 8-12
Rear Travel: 8 in. (203.2 mm)
Rear Suspension: Independent Double A-Arm
Rear Brake Type: Hydraulic Disc
Rear Tires: AT 23 X 10-12
Frame: Steel
Dry Weight: 604.1 lb. (274 kg.)
Towing Capacity: 820 lb. (372 kg.)
Fuel Capacity: 3.96 gal. (15 L)
Ground Clearance: 10.2 in. (259.1 mm)
Machine Dimensions (LxWxH): L: 75 in. (1905 mm); W: 48.4 in. (1229.4 mm); H: 47.6 in. (1209 mm)
Wheelbase: 48.2 in. (1224.3 mm)
Drive Train: Continuously Variable (CVT)
Speedometer: Standard
Odometer: Standard
