Engine Type: Single-Cylinder
Displacement: 4.3 cu. in. (70 cc)
Bore x Stroke: Bore: 1.85 in. (47 mm); Stroke: 1.59 in. (40.3 mm)
Cylinders: 1
Engine Cooling: Air
Fuel System: Gas
Starting System: Electric
Front Suspension: Independent A-Arm
Front Travel: 4 in. (101.6 mm)
Front Brake Type: Hydraulic Disc
Front Tires: OBOR® 18 x 7 - 8
Rear Suspension: Swing Arm
Rear Travel: 4 in. (101.6 mm)
Rear Brake Type: Hydraulic Disc
Rear Tires: OBOR® 18 x 7 - 8
Frame: Steel
Dry Weight: 278 lb. (126 kg.)
Fuel Capacity: 1.5 gal. (5.7 L)
Ground Clearance: 4 in. (100 mm)
Machine Dimensions (LxWxH): L: 56 in. (1422.4 mm); W: 35.5 in. (901.7 mm); H: 35.3 in. (895 mm)
Wheelbase: 37.8 in. (958 mm)
Drive Train: Continuously Variable (CVT)
