Engine Type: Parallel-twin four-stroke
Displacement: 471 cc
Bore and Stroke: 67.0 mm x 66.8 mm
Cooling: Liquid
Compression Ratio: 10.7:1
Transmission: Six-speed
Final Drive: #520 O-ring-sealed chain; 15T/41T
Front Suspension: 41 mm fork
Rear Suspension: Dual shocks with five-position spring-preload adjustability
Front Brakes: Single 310mm disc with two-piston calipers; ABS
Rear Brakes: Single 240mm disc, ABS
Front Tire: 110/80-19
Rear Tire: 150/60-17
Wheelbase: 58.4 in.
Seat Height: 31.1 in.
Rake: 27.0 deg.
Trail: 4.3 in.
Fuel Capacity: 3.2 gal.
Dry Weight: Curb Weight: 419 lb. (Includes all standard equipment, required fluids and full tank of fuel)
Colors: Candy Orange; Mat Laurel Green Metallic
