* Prices shown are based on the manufacturer's suggested retail price (MSRP) and is subject to change without notice. Website price excludes destination charges, setup fees, optional accessories, applicable taxes, license and document fees. Some vehicles are shown with optional accessories which are not included in the price. All sale prices include any factory incentives, factory rebates, and dealer discounts. Engine Type: DOHC 4-stroke; 8 valves
Displacement: 689cc
Bore and Stroke: 80.0mm x 68.6mm
Cooling: Liquid
Compression Ratio: 11.5:1
Fuel System: Fuel Injection
Transmission: 6-speed; wet multiplate clutch
Final Drive: Chain
Front Suspension: 43mm inverted fork, fully-adjustable; 8.3 in. travel
Rear Suspension: Single shock, adjustable preload (w/remote adjuster) and rebound damping; 7.9 in. travel
Front Brakes: Dual 282mm hydraulic disc; selectable ABS
Rear Brakes: 245mm hydraulic disc; selectable ABS
Front Tire: 90/90R21 Pirelli® Scorpion® Rally STR
Rear Tire: 150/70R18 Pirelli® Scorpion® Rally STR
Wheelbase: 62.8 in.
Seat Height: 34.4 in.
Rake: 27 Degrees
Trail: 4.1 in.
Fuel Capacity: 4.2 gal.
Dry Weight: Curb Weight: 452 lb.
Colors: Team Yamaha Blue, Shadow Gray
