Engine Type: Parallel Twin
Displacement: 60.9 cu. in. (999 cc)
Bore and Stroke: Bore: 3.66 in. (93 mm); Stroke: 2.89 in. (73.5 mm)
Cooling: Liquid
Fuel System: Gas
Front Suspension: Independent Double A-Arm
Front Brakes: Hydraulic Disc
Front Tire: Pro Armor® Crawler XP: 30 x 10-15
Rear Suspension: Independent Double A-Arm
Rear Brakes: Hydraulic Disc
Rear Tire: Pro Armor® Crawler XP: 30 x 11-15
Dry Weight: 2790 lb. (1265 kg.)
Wheelbase: 117 in. (2971.8 mm)
Front Travel: 14 in. (356 mm)
Rear Travel: 15 in. (381 mm)
Ground Clearance: 14 in. (356 mm)
Fuel Capacity: 12.5 gal. (47.3 L)
Box Capacity: 600 lbs. (272 kg.)
Towing Capacity: 2000 lb. (907 kg.)
Drive System: Continuously Variable (CVT)
Speedometer: Standard
Tachometer: Standard
Odometer: Standard
