Displacement: 1,552 cc (95 ci)
Engine Type: Four-stroke, SOHC, four valves per cylinder, 50-degree V-twin
Bore and Stroke: 102.0 mm x 95.0 mm
Cooling: Liquid
Compression Ratio: 9.0:1
Fuel System: Digital fuel injection with dual 40 mm throttle bodies
Ignition: Dual Plug TCBI with digital advance
Front Suspension: 43 mm inverted cartridge fork; Wheel travel: 5.9 in.
Rear Suspension: Dual air-assisted shocks with four-way rebound damping; Wheel travel: 3.4 in.
Front Brakes: Dual 320 mm hydraulic discs with radial-mount four-piston calipers
Rear Brakes: 300 mm disc
Front Tire: 130/90x17
Rear Tire: 170/60x17
Wheelbase: 67.1 in.
Seat Height: 27.6 in.
Rake: 32°
Trail: 5.7 in.
Fuel Capacity: 4.5 gal
Dry Weight: 640 lbs
Transmission: Five-speed
Final Drive: Shaft
Colors: Candy Fire Red, Special Edition: Metallic Diablo Black
