Engine Type: 4-stroke, Single
Displacement: 249cc
Bore and Stroke: 77.0 x 53.6 mm
Cooling: Liquid
Compression Ratio: 13.7:1
Fuel System: Fuel injection: ø43 mm x 1 (Keihin) with dual injection
Ignition: Digital DC-CDI
Front Suspension: 48 mm inverted Separate Function front Fork (SFF) Type 2 with 22-position compression, 20-position rebound damping and 40-position spring preload
Front Brakes: Single semi-floating 270 mm petal disc
Front Tire: 80/100-21 51M
Rear Suspension: New Uni-Trak linkage system shock with 19-way low-speed and 4-turn high-speed compression damping, 22-way rebound damping and fully adjustable spring preload
Rear Brakes: Single 240 mm petal disc
Rear Tire: 100/90-19 57M
Dry Weight: Curb Weight: 104.3 kg
Fuel Capacity: 6.4 L
Wheelbase: 1,475 mm (58.1 in.)
Ground Clearance: 324 mm
Seat Height: 945 mm
Trail: 123 mm (4.8 in.)
Rake: 28.4 deg.
Transmission: 5-speed, constant mesh, return shift
Final Drive: Chain
Colors: Lime Green
