Engine Type: 2-stroke
Displacement: 599cc
Bore x Stroke: 73.8 x 70 mm
Cylinders: 2
Engine Cooling: Liquid
Carburetion: 47 mm dual throttle body batteryless EFI
Ignition: 3D sequential fire, throttle position sensor
Exhaust: APV with tuned pipe, pipe sensor and stainless steel muffler
Brake Type: Radial master cylinder hydraulic brake / disc on driveshaft
Drive Clutch: Arctic 6 post (rpm sensing)
Driven Clutch: 10.75 in. dia. Arctic (roller cam)
Front Suspension: Arctic Race Suspension with FOX FLOAT 3 shocks and sway bar
Front Travel: 10 in.
Rear Suspension: FasTrack slide-action suspension with Tri-hub rear axle system, couple blocks, torque sensing link, adjustable torsion springs, Arctic Cat (IFP) shocks (2" dia. rear shock)
Rear Travel: 13.5 in.
Ski Type: Trail 6 in.
Ski Stance: 42-43 in. adjustable
Track Type: Ripsaw
Track Dimensions: 15 in. W x 129 in. L x 1.25 in. H x 2.86 in. Pitch
Headlight: Dual Halogen Headlight (2-Bulb)
Fuel Capacity: 12 gal.
Windshield: Mid
Color: Black
Electric Start: Standard
Hand & Thumb Warmers: Standard
Reverse: Push Button
Mirrors: Optional
