Engine Type: SOHC 4-stroke; 2 valves
Displacement: 90cc
Bore x Stroke: 47.0mm x 51.8mm
Engine Cooling: Air
Fuel System: 13mm Carburetor
Starting System: Electric & Kickstart
Front Suspension: Single A-arm
Front Travel: 5 in.
Front Brake Type: Dual Drum
Front Tires: AT19 x 7-8
Rear Suspension: Monoshock swingarm
Rear Travel: 5.7 in.
Rear Brake Type: Drum
Rear Tires: AT18 x 9-8
Dry Weight: Curb Weight: 139.6 kg. (307.8 lb.)
Fuel Capacity: 6.4 L (1.7 gal)
Ground Clearance: 104.14mm (4.1 in.)
Machine Dimensions (LxWxH): 1,562.1mm (61.5 in.) x 1031.24mm (40.6 in.) x 1005.84 (39.6 in.)
Wheelbase: 1031.24 (40.6 in.)
Final Drive: O-ring Chain Drive
Transmission: CVT; F, N, R
Colors: Yamaha Blue; Armour Grey
