Engine Type: 4-stroke
Displacement: 1049cc
Bore x Stroke: 82 x 62.2 mm
Cylinders: 3
Engine Cooling: Liquid
Carburetion: 3 x 41 mm fuel injection
Ignition: Digital T.C.I. with throttle position sensor
Exhaust: 3 into 1 stainless steel pipe with stainless steel muffler
Brake Type: Radial master cylinder hydraulic brake / disc on driveshaft
Drive Clutch: Arctic 6 post (rpm sensing)
Driven Clutch: 10.75 in. dia. Arctic (roller cam)
Front Suspension: Arctic Race Suspension with FOX FLOAT 3 shocks and sway bar
Front Travel: 10 in.
Rear Suspension: FasTrack Rear Suspension with tri-hub rear axle system, FOX FLOAT 2 rear-arm shock, Arctic Cat (IFP) front-arm shock
Rear Travel: 14.5 in.
Ski Type: Mountain 6 in.
Ski Stance: 42-43 in. adjustable
Track Type: Cobra
Track Dimensions: 15 in. W x 141 in. L x 1.6 in. H x 3.00 in. Pitch
Headlight: Dual Halogen Headlight (2-Bulb)
Fuel Capacity: 10.6 gal.
Windshield: Low
Color: Black
Electric Start: Standard
Hand & Thumb Warmers: Standard
Reverse: Push-Button
Mirrors: Optional
