Displacement: 1083cc
Engine Type: 22.5 deg. parallel-twin four-stroke
Bore and Stroke: 92.0mm x 81.5mm
Cooling: Liquid
Compression Ratio: 10.1:1
Fuel System: PGM-FI electronic fuel injection; 46mm throttle body; throttle by wire
Transmission: Six-speed Automatic DCT
Final Drive: #525 O-ring-sealed chain; 16T/42T
Front Suspension: 43mm fork; 4.8-inch travel
Rear Suspension: Dual Showa shocks with 12.5mm shafts, adjustable preload, and piggyback pressurized reservoirs; 3.7-inch travel
Front Brakes: Single 330mm disc with radial-mount four-piston caliper; ABS
Rear Brakes: Single 256mm disc; ABS
Front Tire: 130/70-18
Rear Tire: Rear Tire: 180/65-16
Wheelbase: 59.8 in.
Seat Height: 27.5 in.
Rake: 28.0 deg.
Trail: 4.3 in.
Fuel Capacity: 3.6 gallons including 1.1-gallon reserve
Dry Weight: Curb Weight: 509 lb.
Colors: Gray Metallic
