Engine Type: 20-deg. single-cylinder four-stroke
Displacement: 286cc
Bore and Stroke: 76.0mm x 63.0mm
Cooling: Liquid
Compression Ratio: 10.7:1
Fuel System: Fuel injection; 38mm throttle body
Transmission: Six-speed
Final Drive: O-ring-sealed chain; 14T/36T
Front Suspension: 41mm telescopic fork; 4.6-in. travel
Rear Suspension: Pro-Link® single shock; 5.2-in. travel
Front Brakes: Single 296mm disc; ABS
Rear Brakes: Single 220mm disc; ABS
Front Tire: 110/70-17
Rear Tire: 150/60-17
Wheelbase: 53.3 in.
Seat Height: 31.6 in.
Rake: 24.0 deg.
Trail: 3.7 in.
Fuel Capacity: 2.6 gal.
Dry Weight: Curb Weight: 316 lb.
Colors: Pearl Dusk Yellow, Matte Black Metallic
