Engine Type: Single-Cylinder
Displacement: 5.5 cu. in. (90 cc)
Cylinders: 1
Bore x Stroke: Bore: 1.85 in. (47 mm); Stroke: 2.04 in. (51.8 mm)
Engine Cooling: Air
Fuel System: Gas
Starting System: Electric / Kick
Front Suspension: Independent A-Arm
Front Travel: 2.8 in. (71 mm)
Front Brake Type: Dual Drum
Front Tires: Kenda AT 20 X 7-8
Rear Suspension: Swing Arm
Rear Travel: 2.9 in. (73 mm)
Rear Brake Type: Hydraulic Disc
Rear Tires: Kenda AT 19 X 8-8
Frame: Steel
Dry Weight: 283 lb. (128.5 kg.)
Fuel Capacity: 1.5 gal. (5.7 L)
Ground Clearance: 4.3 in. (109 mm)
Machine Dimensions (LxWxH): L: 59 in. (1500 mm); W: 34.5 in. (875 mm); H: 37.9 in. (962 mm)
Wheelbase: 38 in. (965 mm)
Drive Train: Continuously Variable (CVT)
