Engine Type: Wet-sump single-cylinder four-stroke
Displacement: 420cc
Bore x Stroke: 86.5mm x 71.5mm
Cylinders: 1
Engine Cooling: Liquid
Fuel System: Programmed Fuel Injection (PGM-FI); 34mm throttle body
Starting System: Electric with optional auxiliary recoil
Front Travel: 6.7-in.
Front Suspension: Independent double-wishbone
Front Brake Type: Dual 190mm discs
Front Tires: 24 x 8-12
Rear Suspension: Swingarm with single shock
Rear Travel: 6.7-in.
Rear Brake Type: 160mm sealed mechanical drum
Rear Tires: 24 x 10-11
Dry Weight: Curb Weight: 615 lb.
Front Rack Capacity: 66 lb.
Rear Rack Capacity: 133 lb.
Fuel Capacity: 3.9 gal., including 1.3-gal. reserve
Ground Clearance: 7.1 in.
Machine Dimensions (LxWxH): 82.8 in. x 47.4 in. x 46.2 in.
Wheelbase: 50.0 in.
Final Drive: Direct front and rear driveshafts with TraxLok® and torque-sensitive front differential
Transmission: Five-speed manual with reverse; electric shifting
Colors: Honda Phantom Camo®
