Engine Type: Single-Cylinder
Displacement: 5.4 cu. in. (89 cc)
Bore x Stroke: Bore: 1.85 in. (47 mm); Stroke: 2.04 in. (51.8 mm)
Cylinders: 1
Engine Cooling: Air
Fuel System: Gas
Starting System: Electric / Kick
Front Suspension: Independent A-Arm
Front Travel: 2.8 in. (71.1 mm)
Front Brake Type: Dual Drum
Front Tires: Maxxis® AT 18 x 7 - 8
Rear Travel: 2.9 in. (73.7 mm)
Rear Suspension: Swing Arm
Rear Brake Type: Hydraulic disc
Rear Tires: Maxxis® AT 18 x 9 - 8
Frame: Steel
Fuel Capacity: 1.4 gal. (5.3 L)
Ground Clearance: 3.9 in. (99 mm)
Machine Dimensions (LxWxH): L: 56.1 in. (1425 mm); W: 35.6 in. (904.2 mm); H: 36.4 in. (925 mm)
Wheelbase: 38 in. (965.2 mm)
Drive Train: Continuously Variable (CVT)
