Engine Type: OHV longitudinally mounted single-cylinder four-stroke engine
Displacement: 475cc
Cylinders: 1
Bore x Stroke: 92.0 mm x 71.5 mm
Engine Cooling: Liquid
Fuel System: PGM-FI
Starting System: Electric with optional auxiliary recoil
Front Suspension: Independent double-wishbone
Front Travel: 7.28 in.
Front Brake Type: 190 mm hydraulic discs
Front Tires: 25 x 8-12
Rear Travel: 8.46 in.
Rear Suspension: Independent dual-arm
Rear Brake Type: 170 mm hydraulic disc
Rear Tires: 25 x 10-12
Dry Weight: Curb Weight: 690 lb.
Towing Capacity: 1322 lb.
Fuel Capacity: 3.9 gal., including 1.3-gal. reserve
Ground Clearance: 9.4 in.
Machine Dimensions (LxWxH): 84.5 in. x 47.4 in. x 48.6 in.
Wheelbase: 50.9 in.
Drive Train: Direct front and rear driveshafts with TraxLok® and locking front differential
Transmission: Five-speed with reverse
Colors: Red, Olive, Orange
